| Technology |
Fused Filament Deposition Modeling
|
| Print volume (L x W x H) |
Printing with main nozzle:
256*256*260 mm³
Printing with auxiliary nozzle:
235.5*256*256 mm³
Printing with dual nozzle:
235.5*256*256 mm³
Total volume for both nozzles:
256*256*260 mm³
|
| Print Speed |
Maximum print head speed: 1000 mm/s
Maximum print head acceleration: 20,000 mm/s²
|
| Maximum Nozzle Temperature |
300 °C
|
| Nozzle Diameter Included |
0.4 mm
|
| Filament diameter |
1.75 mm
|
| Supported nozzle diameter |
0.2mm, 0.4mm, 0.6mm, 0.8mm
|
| Main extruder gear |
Hardened Steel
|
| Main extruder motor |
Bambu Lab High Precision Permanent Magnet Synchronous Motor
|
| Buzzard |
Hardened Steel
|
| Filament cutter |
Integrated
|
| Chassis |
Plastic and Steel
|
| Outer frame |
Plastic, Glass and Metal
|
| Physical Dimensions |
392*406*478 mm³
|
| Net weight |
16.25 kg
|
| Supported print bed types |
Textured PEI top, smooth PEI top
|
| Maximum temperature of the heating plate |
120 °C
|
| Air filter |
G3 Pre-Filter
H12 HEPA Filter
Granulated coconut shell
VOC filtration: Superior.
Particle filtration: Supported.
|
| Camera integrated inside the machine |
Live camera: 1920*1080
Integrated Toolhead Camera; 1600*1200
|
| Sensors |
Door sensor,
filament end sensor, filament tangle sensor
Filament odometry (Supported with AMS)
Power loss recovery
|
| Main print head |
PLA, PETG, ABS, ASA, TPU, PLA compatible, PLA/PETG compatible, ABS compatible, PA/PET compatible, PET, PA, PC, PVA; PLA, PETG, ABS, ASA, PA6, PAHT, PPA, PET reinforced with carbon/glass fibers
|
| PLA auxiliary print head |
(excluding PLA Aero), PETG, ABS, ASA, TPU for AMS, PLA compatible, PLA/PETG compatible, ABS compatible, PA/PET compatible, PET, PA, PC, PVA; PLA, PETG, ABS, ASA, PA6, PAHT, PET reinforced with carbon/glass fibers
|
| Auxiliary print head (print with care¹) |
Silky PLA, PETG-CF, ASA-CF, PA6-CF, TPU for AMS, PA/PET compatible
|
| Maximum extruder temperature |
350 °C
|
| Maximum room temperature |
65 °C
|
| Maximum heating plate temperature |
120 °C
|
| Active room heating |
Support
|
| Supported print bed type |
Textured PEI top, smooth PEI top
|
| Cooling: Closed-loop control |
Cooling fan for parts,
Cooling fan for hotend,
Main control board fan,
Chamber exhaust fan,
Chamber heat circulation fan,
Auxiliary parts cooling fan
|
| Operating temperature |
10 °C–30 °C
|
| Touch screen |
5-inch touchscreen 1280*720
|
| Storage |
8GB integrated EMMC and USB port
|
| Control interface |
Touchscreen, mobile app, PC app
|
| Motion controller |
Dual-core Cortex-M4 and single-core Cortex-M7
|
| Application processor |
Quad-core ARM with dedicated NPU
|
| Slicer |
Bambu Studio
is compatible with third-party slicers that generate standard G-code, such as Super Slicer, PrusaSlicer, or Cura. However, some advanced features may not be supported.
|
| Supported operating systems |
macOS, Windows, Linux
|
| Wireless network |
Dual-band Wi-Fi
|
| Network shutdown switch |
Not available
|
| Removable network module |
Not available
|
| 802.1X network access |
Not available
|
| Wi-Fi Operating frequency |
2412–2472 MHz, 5150–5850 MHz (FCC/CE)
2400–2483.5 MHz, 5150–5850 MHz (SRRC)
|
| Wi-Fi transmitter power (EIRP) |
2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5 GHz band 1/2: <23 dBm (FCC/CE/SRRC/MIC)
5 GHz band 3: <30 dBm (CE); <24 dBm (FCC)
5 GHz Band 4: <23 dBm (FCC/SRRC); <14 dBm (CE)
|
| Wi-Fi Protocol |
IEEE 802.11 a/b/g/n
|
